Features：
•2MP CMOS covert pinhole buttoncamera
•1080p, 0.03 Lux@F2.0(50IRE) low light sensitivy
•Self-contained invisible microphone, single cable design
•Adopts lightweight, ultra-thin design cables
•Provides flexibility to disguise in different application
•Low cost while with high performance solution
Specifications：
|
Built in Image Sensor |
1/2.9" progressive CMOSSensor |
|||
|
Sensor Resolution |
2000x1121 |
|
||
|
Pixel Size |
2.8um(H) * 2.8um(V) |
|||
|
Digital Picture Resolution |
(H)1920x(V)1080 |
|||
|
Sensor Sensitivy |
0.03 Lux @ F 2.0 |
|||
|
Lens F/No. |
F2.0 |
|||
|
Focal Length |
4.3mm |
|||
|
Angle of view |
78° |
|
|
|
|
Depth of View |
50 cm ~ ∞ |
|||
|
Electronic Shutter |
1/8 ~ 1/30,000 |
|
||
|
Video Output |
I2C Data |
|||
|
Power Supply Current |
220mA |
|||
|
OperatingTemperature |
-10℃ ~ 60℃ |
|||
|
OperatingHumidity |
20 ~ 90% |
|
|
|
|
Storage Temperature |
-30℃ ~ 80℃ |
|||
|
Power Input |
DC 3.3V± 5% |
|||
|
Dimension |
25x25x17mm |
|||
|
Weight |
18g |
|||
※ OTP-BU18HD is not compatible with RF wireless transmitters.
※ OTP-BU18HD is only compatible with OTP-500HDW & OTPP-500HDW Pro.
*Specifications are subject to change without prior notice.
